Autex Acoustics - Lattice

Autex Acoustics - Lattice

Color Petronas
View full details
  • A collection of acoustic baffles that are suspended or direct fixed to ceiling space. A simple out of the box acoustic solution, Lattice™ easily creates a point of interest in any space.



    Features and Benefits
    • Get in touch and one of the team can assist in creating a cart with exactly what you're looking for
    • Lead time is two weeks from date of order/payment plus shipping
    • Assembly Instructions inside the pack
    • Size and Packs vary by design, see below
    • Comes with suspension kits
    • Delivers excellent acoustic performance
    • Covers a greater surface area than traditional parallel fin systems for optimum acoustic absorption
    • Made locally





    Lattice™ in Action

    "Our cool new space is really noisy and it's hard for the teachers and children to hear. What can we do?"

    Lighthouse Learning Centre Howick started its life as a church and was repurposed as a preschool.

    The new owners engaged the team at Acoustic Solutions Store to consult on the reverberation issues in the space. The feedback from the teachers was it was super noisy when the kids were inside.

    8 x Autex Acoustics Lattice Eclipse Baffles were installed and serve as an aesthetic and acoustic triumph, suspended high in the octagonal pyramid ceiling space.

    The teachers and children now enjoy superior acoustics in the space and have an excellent environment in which to play and learn.



      • Sabin: Varies by design, refer to the brochure
      • Composition: 100% polyester fibre (PET)
      • Size:

        Eclipse: 1197 mm x 2346 mm x 337 mm (1 per pack)

        Torus: 1450 mm x 1450 mm x 293 mm (2 per pack)

        Trapezium: 1180 mm x 2380 mm x 290 mm (1 per pack)

      • Thickness: 12 mm
      • Product Placement: Ceiling
      • Form: Baffle
      • Install method: Suspended
      • Application: Open Plan Offices, Commercial/Office Space, Education, Hospitality, Theatres and Auditoriums
